Key attributes
| Place of Origin | Guangdong, China | Condition | New |
| Weight (KG) | 1200 | Video outgoing-inspection | Not Available |
| Machinery Test Report | Not Available | Warranty of core components | Not Available |
| Core Components | Gear | Warranty | 3 months |
| Applicable Industries | electrical power insulation | Showroom Location | United States, Brazil |
| Brand Name | SWETE | Clamp plate size | 600*800mm |
| Clamp force | 18T | Min-max clamp plate stroke | 240*1250mm |
| Upper&lower core puller stroke | 760*350mm | Heating power | 24KW |
| Hydraulic power pack | 7.5KW | Horizontal tilting angle | 0-5° |
| Mould load weight | 2T | Machine weight | 7500KG |
| Machine dimension | 7300*1300*3100mm | Supply Ability | 100 Set/Sets per Month |
*Double-station APG Clamping Machine
Application
This machine is designed with 2 workstations, the clamp plate size is 600X800mm, supports 2 molds working on the same machine, greatly improving the efficiency, it is specially used for producing simply designed products, such as insulators, bushing, and sensors.
Machine Technical Parameters
Item | Parameter |
Clamp Plate Size | 600*800mm |
Clamp Force | 18T |
Min MAX Clamp Plate Stroke | 240*1250mm |
Upper&Lower Core Puller Stroke | 760*350mm |
Heating power | 24KW |
Hydraulic power pack | 7.5KW |
Horizontal tilting angle | 0-5° |
Mould load weight | 2T |
Machine weight | 7500KG |
Machine dimension | 7300*1300*3100mm |
We provide a one-stop professional APG Machine, APG Mould, APG Technology, Oven for APG Processing, Testing equipment, Epoxy resin material, Silicone material, Release mold agent, CT&PT Toroidal Winding Machine, Transformer Foil Winding Machine, Laser Marking Machine, etc.
Any questions or inquiries, pls leave a letter to know more details about Prices, Packing, Shipping, and discounts. We have more than 24 years of the original factory here and waiting for your answer to give you the best price and solution.
